Question

How do I adjust the fuel level on my carburetor?

Answer

Setting the fuel level should be the first thing you do before attempting to make any further adjustments.The float level should put the fuel level just below the bottom of sight plug hole. You will make the adjustment with the vehicle on a level surface and the engine idling. You will first remove the sight plug, then to make your adjustment you will need to loosen the lock screw on the needle and seat. This will allow you to turn the adjusting nut to raise or lower the float level. Each hex flat on the nut will change the float level approximately 1/32". When you have the fuel level just below sight plug hole you will then tighten the lock screw and reinstall the sight hole plug. Make sure you have a shop towel handy in case you have any fuel leaks from the Sight plug or needle and seat adjusting nut.

Question

I have a vacuum secondary carburetor that bogs when the secondaries come in. What will cause this?

Answer

Bogging and hesitation are caused by the secondaries coming in too quickly. You can install a heavier secondary spring and this will prevent the secondary from coming in too soon. If the engine is sluggish in response at full throttle then the secondaries may not be opening soon enough. You will then need to go to a lighter spring. The spring kit is part number 20-13 which will have 7 different springs to fine tune with.

Question

My vehicle has a stumble from a dead stop. What can I do to cure this?

Answer

My vehicle has a stumble from a dead stop. What can I do to cure this?The most common cause of a stumble is not having an adequate accelerator pump shot. The first thing to do is to look at the discharge nozzle and make sure you are getting a good strong pump shot. If not then you need to inspect the pump diaphragm for a hole or tear. You will also need to make sure that the pump passage is clear from any trash or debris. First you will need to check the adjustment on the pump. To do this you will open the throttle all the way (WOT). Push the pump arm lever down and then adjust the pump override spring to obtain .015" clearance between the pump arm and lever. If you are having a stumble and no black smoke out the tailpipe then you will need to increase the shooter size. If it stumbles and you are getting black smoke from the tailpipe then it will be necessary to decrease the shooter size.

Question

I can rev the engine when it is in park and the secondaries will not open. Why is this?

Answer

The secondaries will not open by free revving the engine. The engine needs to be under a load before they will open. If you are still uncertain if they are opening or not you can take a normal paperclip and clip it onto the secondary diaphragm rod. You will then push it up against the bottom of the secondary diaphragm housing, now you will need to go out and drive the vehicle. When you return you will be able to look at the position of the paperclip on the rod. If it is lower on the rod then you can tell the secondaries opened and how far they opened. This is useful in determining if you need a heavier or lighter secondary spring.

Question

How do I know if a vacuum or mechanical carburetor is best for me?

Answer

For street cars the vacuum secondary carburetor works best on midweight or heavyweight cars with an automatic transmission. They are more forgiving than a Double Pumper is because they work by sensing engine load. The mechanical secondary carburetor is best on a lighter car with radical camshaft and a lower gear and manual transmission or on a car that is going to be used for racing purposes.

Here are some additional resources for you to see on Holley TV. Overview Of 4150 Vacuum Secondary Carburetor, Click Here To View. Overview of 4150 Mechanical Secondary Carburetor, Click Here To View.

Question

I just bought a new carburetor and it has a warning that it will not work with an automatic overdrive transmission. What can I do about this?

Answer

This warning was placed with the carburetor because if not installed properly with the correct transmission kickdown bracket for the GM 700R4 it will result in premature transmission failure. Part #20-95 and the kickdown mounting stud part #20-40 will allow the proper adjustment of the cable.

Question

How do I find the "list" number on my carburetor?

Answer

The list number for most performance and factory 2 and 4 barrel carburetors will be found stamped into the upper right hand corner of the airhorn or sometimes called the choke tower. On the 4150 HP models that do not have a choke tower the list number will be stamped into the mainbody behind the throttle linkage. This number is used to identify the carburetor and also used when needing service parts or renew kits.

Question

After I shut my car off and come back out the next morning there is gas on the throttle shaft and puddled on the intake. What causes this?

Answer

This is usually caused by percolation. This is when the engine is shut off and the engine temperature rises it causes the fuel to boil in the bowl and leak out of the boosters. There are a couple of things you can do to cure this one is make sure the fuel level is not too high. You can also lower the fuel level about 1/8" below the sight plug hole and this will cure it sometimes. The heat from the engine will rise into the carburetor sometimes and will cause the fuel to boil. Installing a phenolic heat spacer between the carburetor and the intake or a heat shield can cure this. These parts will prevent heat from getting to the carburetor and boiling the fuel.
